Parameter Items | XT series touch foil technical specifications | |||
Technical
principle |
Improved projected capacitive touch technology, metal printed grid matrix replaces ITO layer. | |||
Product Series | XTM | XTA | XTB | XTC |
IMAGE | ||||
Touch points | 12 points | 20 points | 30 points | 40 points |
Size | 15-32inch | 32-55inch | 55-86inch | 43-120inch |
Touch deviation | ≤0.5mm | ≤0.5mm | ≤0.5mm | ≤0.5mm |
Number of | TX28 RX48 | TX56 RX96 | TX80 RX142 | TX136 RX240 |
Scanning speed | 8 millisecond/frame | 8 millisecond/frame | 8 millisecond/frame | 8 millisecond/frame |
Energy
consumption |
1W | 1W | 1.3W | 2.5W |
Drive type | Drive free | Drive free | Drive free | Drive free |
Windows | Win7/8/8.1/10 | Win7/8/8.1/10 | Win7/8/8.1/10 | Win7/8/8.1/10 |
Andriod | Kernel 3.10 or higher | Kernel 3.10 or higher | Kernel 3.10 or higher | Kernel 3.10 or higher |
Linux | Kernel 3.10 or higher | Kernel 3.10 or higher | Kernel 3.10 or higher | Kernel 3.10 or higher |
Arm Reject | Support | Support | Support | Support |
Support
customization |
Support | Support | Support | Support |
Waterproof
support |
Support | Support | Support | Support |
Deviation calibration | Software calibration | Software calibration | Software calibration | Software calibration |
Technical
certification |
CE、ilac-MRA、CNAS、CAL、CMA、FCC、ROHS、ISO | |||
Packing list | Touch foil*1 E-board*1 USB cable*1 | |||
Film thickness | ≤200um | |||
Transmittance | More than 93% | |||
Supply voltage | 5V | |||
Transfer method | USB2.0 | |||
Transmission
distance |
≤50m (Add USB signal amplifier etc.) | |||
Safe distance | 2mm(Refers to the distance between the LCD screen and the film) | |||
Ambient temperature | -20℃ to +70℃ | |||
Ambient light | Full-angle anti-glare illumination | |||
Touch support | Click, drag, zoom in, zoom out, rotate | |||
Sensing distance | ≤10mm | |||
Note: The above is exemplified by a 43-inch film and a 5 mm thick glass. |
